FlashArray//C90 R4 (QLC capacity-optimized all-flash)
All-flash economics at petabyte scale for tier-2 and capacity workloads.
We help you choose, configure, and deliver the right system — no obligation.
Configuration at a Glance
Tailored per engagement. Full technical overview below.
Overview
FlashArray//C90 R4 is the capacity-optimized member of the FlashArray family, using high-density QLC DirectFlash Modules to deliver all-flash performance and resiliency at the cost profile of disk. Nexus Compute specifies, configures, and tests each system, arranging Evergreen-backed support and delivery through authorized channels.
Who This Solution Is For
Business Benefits
Disk economics, flash benefits
QLC DirectFlash delivers all-flash latency and reliability at a cost-per-terabyte near hybrid disk arrays.
Dense petabyte capacity
75TB QLC modules pack up to 1.5PB per rack unit, shrinking floor space and power for large data sets.
Unified operations
Identical Purity management and Evergreen lifecycle as //X and //XL simplify multi-tier estates.
Typical Business Use Cases
Tier-2 and capacity-tier consolidation
Flash-class disaster recovery and replication targets
Large database and VM repositories
Policy-based snapshots and retention
Industry Applications
Technical Overview
FlashArray//C90 R4 runs Purity//FA on dual active-active controllers populated with QLC DirectFlash Modules (with onboard NVRAM), reaching up to 8.9PB effective capacity in a 6U chassis at a 5:1 reduction ratio. Each PCIe 4.0 x16 networking port runs full line rate, supporting two ports of 100GbE, four of 25GbE, or four of 64Gb FC with NVMe/TCP.
| Architecture | Dual active-active controllers, capacity-optimized |
| Media | 75TB / 36TB QLC DirectFlash Modules (DFMD) |
| Effective Capacity | Up to 8.9PB at 5:1 reduction (6U chassis) |
| Density | Up to ~1.5PB per rack unit |
| Host Connectivity | 2x100GbE, 4x25GbE, or 4x64Gb FC; NVMe/TCP |
| Data Services | Dedup, compression, snapshots, replication, SafeMode |
| Form Factor | 6U chassis, expandable with DirectFlash shelves |
| Management | Purity//FA, Pure1; Evergreen subscription support |
Specifications are indicative and configured to each engagement. Request a quote for a configuration tailored to your requirements.
Warranty, Support & Fulfillment
Every system ships from an authorized channel, configured and tested, with the documentation enterprise buyers need — backed by warranty and a dedicated account team.
Enterprise Warranty
Full manufacturer warranty with optional on-site, next-business-day support and extended coverage.
Authorized Channel
Sourced through Tier-1 distribution and OEM partners — never grey market. Asset & warranty records included.
Lead Time & Deployment
48-hour quotes, then configured, burn-in tested, and delivered on a committed schedule.
Nationwide Fulfillment
Coordinated logistics, rack-and-stack, and delivery wherever your infrastructure lives.
Frequently Asked Questions
Is QLC reliable enough for production?
Yes. //C90 uses QLC DirectFlash Modules managed directly by Purity, which handles wear and data placement at the array level, delivering all-flash resiliency and Evergreen-backed support for production capacity workloads.
What workloads suit //C versus //X?
//C is built for capacity-tier and cost-sensitive data such as DR targets, large repositories, and tier-2 databases. //X and //XL serve latency-critical tier-1 workloads. Many customers run both under one Purity management plane.
How much rack space does a petabyte take?
With 75TB QLC modules, //C90 reaches roughly 1.5PB per rack unit, so multi-petabyte estates fit in a single 6U chassis with room to expand via DirectFlash shelves.
